Standards for EV Charging Couplers
IEC 62196-1 /EN 62196-1 = Part 1: General requirements
IEC 62196-2 /EN 62196-2 = Part 2: Dimensional compatibility and interchangeability requirements for AC pin and contact-tube accessories
IEC 62196-3 /EN 62196-3= Part 3: Dimensional compatibility and interchangeability requirements for d.c. and a.c./d.c. pin and contact-tube vehicle couplers
Chinese GB/T 20234.1/.2/.3: Connection set of conductive charging for electric
GB/T 20234.1 = Part 1: General requirements
GB/T 20234.2 = Part 2: AC charging coupler
GB/T 20234.3= Part 3: DC charging coupler
SAE J1772 = SAE Electric Vehicle and Plug in Hybrid Electric Vehicle Conductive Charge Coupler
Standards for EV Charging Stations (Electric vehicle conductive charging system)
IEC 61851-1= Part 1: General requirements
IEC 61851-21 = Part 21-1: Electric vehicle onboard charger EMC requirements for conductive connection to an AC/DC
IEC 61851 = Part 21-2: EMC requirements for OFF board electric vehicle charging systems (under preparation) supply
IEC 61851-22 = Part 22: AC electric vehicle charging station (in future merged with 61851-1)
IEC 61851-23 = Part 23: DC Electric vehicle charging station
IEC 61851-24 = Part 24: Control communication protocol between off-board DC charger and electric vehicle
IEC 62752 = In-cable control and protection device for mode 2 charging of electric road vehicles (IC-CPD)
NASC North American Charging Standard (Tesla standard = Electric Vehicle (EV) and Electric Vehicle Supply Equipment (EVSE) systems for both AC and DC charging systems
Standards for EV Charging Stations Communication
ISO/IEC 15118-1 = Part 1: General information and use-case definition
ISO/IEC 15118-2 = Part 2 Technical protocol description and Open Systems Interconnections (OSI) layer requirements
ISO/IEC 15118-3= Part 3: Physical layer and Data Link layer requirements
EV-labelling_Operators
for new vehicles and all fuel pumps/recharging stations to be labelled in order to enable vehicle drivers to be easer select the fuel or recharging operate on that their vehicle can properly use.
The Directive regulates the deployment of a new, unique and harmonised set of fuel and electric charging labels.
For the electric vehicles these labels will appear:
